Manage the Modem Router and Monitor the Traffic
241
AC1600 WiFi VDSL/ADSL Modem Router Model D6400
The user name is admin. The default password is password. The user name and
password are case-sensitive.
4. Click the OK button.
The BASIC Home screen displays.
5. Select Attached Devices.
The Attached Devices screen displays.
Wired devices are connected to the modem router with Ethernet cables. WiFi devices are
connected to the modem router through the WiFi network, either in the 2.4 GHz band or
the 5 GHz band.
The following table describes the fields on the Attached Devices screen.
Field Description
Status The access control status (Allowed or Blocked).
Device Name The device name, if detected.
IP Address The IP address that the modem router assigned to the device when it joined the network.
This address can change when a device is disconnected and rejoins the network.
MAC Address The unique MAC address of the device. The MAC address does not change and is
usually shown on the product label.
Connection Type The type of connection for the device (Wired or Wireless).
6. To refresh the information onscreen, click the Refresh button.
The information onscreen is updated.
Monitor and Meter Internet Traffic
Traffic metering allows you to monitor the volume of Internet traffic that passes through the
modem router Internet port. With the traffic meter utility, you can set limits for traffic volume,
set a monthly limit, and get a live update of traffic usage.
Start the Traffic Meter Without Traffic Volume Restrictions
You can monitor the traffic volume without setting a limit.
To start or restart the traffic meter without configuring traffic volume restrictions:
1. Launch an Internet browser from a computer or WiFi device that is connected to the
network.
2. T
ype http://www.routerlogin.net.
A login screen displays.
3. Enter the user name and password for the modem router.
