3.21 Running Test 3 Tests and Diagnostics
3.21 Running Test
3.21.1 Function Description
This function automatically executes the following tests in sequence:
1. System test (subtest 01)
2. Memory test (subtests 01,02, 04)
3. Display test (subtest 01)
4. FDD test (subtest 02)
5. HDD test (subtests 01)
6. Real timer test (subtest 02)
The system automatically detects the number of floppy disk drives connected to the computer
for the FDD test.
3.21.2 Operations
COUTION: Do not forget to load a formatted work disk in the FDD. If a work disk is not
loaded, an error will be generated during the FDD testing.
1. Remove the diagnostics disk from the floppy disk drive and insert the formatted work
disk.
2. Select 6-RUNNING TEST from the DIAGNOSTIC MENU and press Enter. The
following message is displayed.
Serial #A wrap around test (Y/N) ?
Select Y (yes) to execute the Serial #A test or N (NO) not to execute, then press
Enter. A RS-232C wraparound connector must be connected to the serial port of the
computer to execute properly this test.
PORTEGE R100 Maintenance Manual (960-440) 3-49
