1 Pin Assignment Appendices
Portégé R100 Maintenance Manual (960-440) 1-11
C.17 PJ8800 DC-IN connector (2pin)
Table C-17 DC-IN connector (2pin)
Pin No. Signal name I/O Pin No. Signal name I/O
1 ADPDC I 2 (GND) -
C.18 PJ8810 Battery connector (10pin)
Table C-18 Battery connector (10pin)
Pin No. Signal name I/O Pin No. Signal name I/O
1 [+] - 2 BTMP1 O
3 DCHG O 4 M5V O
5 PSCL-S5P I/O 6 PSDA-S5P I/O
7 GND - 8 DBT10V-S5N I
9 GND - 10 GND -
C.19 PJ8760 RTC battery connector (3pin)
Table C-19 RTC battery connector (3-pin)
Pin No. Signal name
I/O
Pin No. Signal name
I/O
1 (Vbat) - 2 N.C -
3 GND -
C.20 PJ8780 FAN connector (3pin)
Table C-20 FAN connector (3pin)
Pin No. Signal name
I/O
Pin No. Signal name
I/O
1 FAN VCC O 2 GND -
3 FANG―P3P I
