VERSAJET MP3200
[Notes] For I and II
When standard mode is selected, this command is enabled only when the printing
position is at the head of a line or when no data exists in the print buffer.
The bar code width that exceeds the printing area cannot be specified.
This command specifies m = 0 to 6 and ends with a NUL code.
When page mode is selected, this command develops the bar code data in the print buffer
but the printer does not print the bar code data.
This command feeds as much paper as is required to print the bar code, regardless of the
line spacing specified by line space setting commands.
The bar code is not affected by print mode (emphasized, underline, or 90°
clockwise-rotated), except for upside-down printing mode.
After bar code printing, the printing position moves to the left end of the printing area. The
printer enters the status of printing position at the head of a line or no data exists in the
print buffer.
The values of m from 0 to 6 in M and from 65 to 71 in N select the same bar code system,
respectively. The printing results are the same.
When an odd number of data is processed for ITF bar code system (m = 5), the printer
ignores the last received data.
The printer processes n bytes from the next data as bar code data by this command
specifying m = 65 to 71.
Printing area does not include quiet zone (left/right margin) of bar code. Make sure to
secure the quiet zone, using this command.
164 Preliminary Rev. 02
