Rev.A BIOS Setup 3-21
Developer's Guide SR-600
Confidential
Messages
The message portion of the screen displays the result of tests.
Setup Menu
Following three commands can be executed from the Setup menu.
❏
Drawer Password
It sets the password to access to the drawer kick out test
.
❏
Drawer ON time
It sets the length of time for the voltage signal supplied to the cash drawer solenoid to open
it.
❏
M/B Information
Displays the various informations on the motherboard.
Table 3-14 Message area
Test category Message Description
TM printer Disabled This port is disabled.
Done The TM printer test is completed. Check the printing motion and autocutter
motion.
DM display Disabled This port is disabled.
Done DM display test is completed. Check display.
Drawer kick-out Disabled This port is disabled.
Done The drawer kick-out test is completed. Check the motion of cash drawer.
Loop-back Error The diagnostics test failed. This message also appears when a loop-back
connector is not connected or the wrong loop-back connector is connected.
Disabled This port is disabled.
OK The test completed successfully.
LPT1 print Time out The printer connected to the LPT1 port did not enter a ready state after 2
seconds.
Disabled
This port is disabled.
Ok The print data was sent successfully.
