EPSON Stylus Scan 2500 Revision A
Appendix EEPROM Address Map 146
7.2 EEPROM Address Map
This section provides EEPROM address map for the Stylus Scan.
l
Table 7-15. Printer Unit EEPROM Address Map
Address Explanation Setting
QPIT
Settings
Factory
Settings
00H Password 0 0FH -
01H 5AH -
02H Reserved 41H -
03H Reserved 00H (*1)
04H CG 0: STD, 1: NLSP 00H (*1)
05H Market lD
0: Standard (World)
2: Custom
00H (*1)
06H
Custom EEPROM
sub number
00H 00H
07H 00H 00H
08H 00H 00H
09H 00H 00H
0AH
Head actuator
rank lD for VhN
00H (*1)
0BH
Head actuator
rank ID for Vh
µ
00H (*1)
0CH
Head actuator
rank ID for VhL
00H (*1)
0DH
Head actuator
rank lD for AR
00H (*1)
0EH
Head rank MW-
ID
00H (*1)
0FH Reserved 00H -
10H Reserved 00H -
11H Reserved 00H -
12H
Head actuator
rank lD for lwAB
00H (*1)
13H
Head actuator
rank lD for lwCD
00H (*1)
14H
Head actuator
rank ID for lwEF
00H (*1)
15H
Bi-D Adjustment
data for Normal-
dot
-36<=n=<+36
(by 1/1440 inch)
00H (*1)
16H
Bi-D Adjustment
data for Micro-
dot
-36<=n=<+36
(by 1/1440 inch)
00H (*1)
17H
Bi-D Adjustment
data for Variable-
dot
-36<=n=<+36
(by 1/1440 inch)
00H (*1)
18H
Uni-D adjustment
data
-36<=n=<+36
(by 1/1440 inch)
00H (*1)
19H Reserved 00H -
1AH Reserved 00H -
1BH
1st dot position
adjustment data
-40<=n=<+40
(by 1/1440 inch)
00H (*1)
1CH
Carriage speed
adjustment data
-4<=n<=+4
(by G.A. timer unit)
00H (*1)
1DH
Carriage phase
on Home
00H -
1EH
Paper sensor
adjustment data
-127<=n<=+127
(by 1/720 inch)
00H (*1)
1FH ERROR Code 00H 00H
20H
CPSl password
00H 00H
21H 00H 00H
22H 00H 00H
23H 00H 00H
24H CPSI license flag 0: disable 1: enable 00H 00H
25H CPSl font license 0: disable 1: enable 00H 00H
26H
Interface
selection
0: Auto, 1: Parallel
2: Serial, 3: USB
00H
00H
(*2)
Table 7-15. Printer Unit EEPROM Address Map (cont.)
Address Explanation Setting
QPIT
Settings
Factory
Settings
