96 Troubleshooting the HP JetDirect Print Server
EN
Understanding the Ethernet
Configuration Page (Internal MIO
and EIO Print Servers)
This section describes the Ethernet/802.3 configuration page for
HP JetDirect internal print servers.
Chapter 7, “HP JetDirect Configuration Page Messages,” contains
tables of corresponding configuration page messages listed by
network operating system.
The networking section of the Ethernet/802.3 configuration page is
divided into seven sections. The item numbers in the following table
correspond to the callouts in Figure 6.2 (MIO) and 6.3 (EIO).
Table 6.1 MIO and EIO Ethernet Configuration Pages
(Internal Print Servers) (1 of 2)
Item Description Troubleshooting Information
1 HP JetDirect product
information (Table 7.5)
This section provides product
identification and port selection
information.
2 HP JetDirect print server
status information
(Table 7.5)
This lists error conditions or Ready.
3 Network statistics
(Table 7.5)
This is an example of a network with
good hardware and plenty of
bandwidth. All zeros or a high
percentage of any of the items currently
at zero can indicate network hardware
problems.
4 Novell NetWare status
information (Table 7.1)
This lists information including Network
Frame Types received. This setting
may indicate that the HP JetDirect print
server is locking onto the wrong frame
type, that multiple frames are using the
same network number, and more.
