124 HP JetDirect Configuration Page Messages
EN
PARALL EL
PORT X:
CENTRONICS indicates a standard parallel connection that
transfers data in one direction only (to the printer).
BIDIRECTIONAL indicates a parallel connection that
supports bidirectional communications.
BITRONICS indicates a parallel connection that supports
bidirectional communications.
ECP_MLC or ECP_MLC2 indicates a bidirectional parallel
connection (IEEE-1284) that supports an enhanced
capabilities port.
DISCONNECTED indicates that no printer is attached to the
port or the printer is not turned on.
PASSWORD ERROR The HP JetDirect print server detected that the password
for the NetWare print server object is wrong. Use the
PCONSOLE utility to erase the password for the print server
object. When the HP JetDirect print server logs on again, it
sets a new password.
Note: When multiple file servers are configured, the error is
only displayed on the configuration page if none of the file
servers are connected.
PORT CONFIG Indicates whether the RJ-45 port on the HP JetDirect print
server is configured for network communications using a
10/100Base-TX full- or half-duplex channel. For MIO cards,
a “-M” suffix indicates the configuration has been manually
set using switches or jumpers.
PORT SELECT: Specifies the port on the print server that has been detected
for use: RJ-45, BNC (10Base2), or DB9.
If DISCONNECTED is displayed, verify that the network
cable has been properly attached to the desired port.
POSTSCRIPT MODE
NOT SELECTED
or POSTSCRIPT
UPDATE NEEDED
The printer does not support the EtherTalk MIO extensions.
It may be a printer which does not support AppleTalk. When
this message is displayed, the other AppleTalk messages
(ADDRESS, APPLETALK NAME, ZONE NAME) are not
displayed.
PRINT SERVER NOT
DEFINED
The file server does not have a print server object that
corresponds to the specified NetWare node name. Use
printer installation software or PCONSOLE to create the
print server object.
When the HP JetDirect print server is configured for multiple
file servers, the error is only displayed on the configuration
page if none of the file servers made the connection.
Table 7.5 General HP JetDirect Messages (10 of 15)
Message Description
