126 HP JetDirect Configuration Page Messages
EN
SIGNAL LOSS The HP JetDirect print server has detected a loss of signal
on the ring. Check the cable from the HP JetDirect print
server to the network and check the wiring concentrator.
or
A signal loss condition has been detected at the
HP JetDirect print server receiver input during the open
process (either when wrapped or inserted onto the ring).
SINGLE STATION The HP JetDirect print server has sensed that it is the only
station on the ring.
SQE ERROR Run the power-on self-test: turn the printer off, then on
again. If the error persists, replace the HP JetDirect print
server.
TFTP IN PROGRESS The HP JetDirect print server is currently in the process of
obtaining its basic IP configuration information through
TFTP and has not detected any errors.
TFTP LOCAL ERROR The TFTP transfer of the configuration file from the host to
the HP JetDirect print server failed with the local print server
encountering some form of inactivity timeout, or excessive
retransmissions situation.
TFTP REMOTE
ERROR
The TFTP transfer of the configuration file from the host to
the HP JetDirect print server failed with the remote host
sending a TFTP ERROR packet to the print server.
TFTP RETRIES
EXCEEDED
The overall retrying of the TFTP transfer of the configuration
file from the host to the HP JetDirect print server has
exceeded a retry limit.
TIMEOUT The HP JetDirect print server fails to logically insert onto the
ring before the insertion timer expires. Each phase of the
insertion process must complete before expiration of the
18-second insertion timer.
TOKEN ERRORS: Total number of times a violation of the token-passing
protocol has been detected.
TOTAL PACKETS
RECEIVED:
TOTAL PACKETS
RCVD:
Total number of frames (packets) received by the
HP JetDirect print server without error. This includes
broadcast, multicast packets, and packets specifically
addressed to the print server. This number does not include
packets specifically addressed to other nodes.
TRANSMIT BEACON The HP JetDirect print server is transmitting beacon frames
to the ring.
TRANSMIT ERROR Check the network topology and verify all cable segments.
Table 7.5 General HP JetDirect Messages (12 of 15)
Message Description
