50
Chapter 2 Command Codes
STOP Stop indicates the end of the CORNER command;
enter STOP, and the IGP will wait for a new
command. If not entered, the IGP will wait for
another set of Corner command parameters.
Example The following program specifies a corner set as shown in Figure
6. To illustrate positioning, the starting row and column are
indicated on the example but do not necessarily reflect actual
location on the page. (Note the position of the ending row and
ending column; they do not include the line thickness.)
CORNER
5;27;27;42;55;4;6 (Each corner in the set is 5
STOP dot rows thick, 4 character
rows high, 6 character columns
wide)
Figure 6
. Corner Example
COLUMN 27
ROW 27
COLUMN 55
ROW 42
HORIZONTAL LENGTH
6 COLUMNS
VERTICAL
LENGTH
4 ROWS
