2. General
2.5 Projector air inlets and outlets
Air inlets and outlets
Image 2-8
The CLM HD8 has 2 inlet channels and one air outlet. The air outlet is located at the rear of the projector. The air inlets are located
at the front and top of the projector.
2.6 Free download of Projector Toolset
About Projector Toolset
Projector Toolset is a software tool to set up, congure, manage and control Barco projectors.
The concept of this Projector Toolset software is modular. The basic package can be extended with several optional device plug-in
modules, now and in the future available.
The Projector Toolset software works with congurations that can be loaded. Within a conguration, different snapshots can be
taken. A snapshot represents a current state of a conguration and can be reloaded to return to this typical state. These terms will
be used through the complete software.
Projector Toolset is a stand-alone application that runs on a Java Virtual Machine and that does not require extra services to run.
Several congurations can be controlled simultaneously. Even when the congurations are connected via different ways.
Projector Toolset is only available in a download version, no CD can be ordered.
Where to nd the download le(s)
The program and all necessary plug-ins, as well as the Reference manual can be downloaded for free from Barco’s Partnerzone,
URLh
ttps:\\my.barco.com. Registration is necessary.
If you are not yet registered, click on Partnerzone registration and follow the instructions. With the created login and password, it is
possible to enter the partnerzone where you can download the Projector Toolset software and the device plug-in updates as well as
the corresponding reference manual.
When downloading the complete Projector Toolset, this software contains already the latest device plug-ins. When you already have
the latest core version of Projector Toolset, it is possible to download only device plug-in updates from the same web site location.
As Projector Toolset is a stand alone application, it is not necessary to install any other software. A Java virtual machine is included
with this download.
Installation
Download rst the reference manual (Part number: R59770052) and follow the installation instructions as written in this manual.
