Barco R59770057 Projector User Manual



3. Physical installation
Image 3-18
Mounting to truss
8. Lift up the projector and hook the four rigging clamps over the support bars of the truss.
9. Lock all four rigging clamps.
10.Install the safety cable. Hook one end into a provided h
ole. Route the cable around the truss and hook the other end into a
second hole in the carry handle.
Image 3-19
Security cable
CAUTION: Always mount
the safety cable when suspending the projector.
28 R59770057 CLM HD8 15/03/2010
