6. Getting started
Starting image projection via the standby key.
1. Press Stand by key once on the local keypad or on the remote control.
MENU
EXIT
ENTER
PAUSE
TEXT
PHASE
TINT
COLOR
BRIGHTN
CONTR
9
0
7
8
5
6
3
4
1
2
LENS
LENS
ZOOM
LENS
SHIFT
LENS
FOCUS
L
SHARPN
LENS
SHIFT
1
2
3
4
5
6
7
89
0
MENU
EXIT
ENTER
RGB
STBY
PAUSE TEXT
PATTERN
WINDOW
PIP LENS
RIGGING
AUTO
A
B
Image 6-3
Stand by indication
A Stand by indication on local keypad
B Stand by indication on remote control
The projector status LED lights up.
The projector starts up on the last saved source.
Some lamp and runtime warnings can be dis
played when an image is displayed after a start up.
6.3.2 Errors, warnings and messages during start up
Temperature error DMD
When the temperature of the DMD is too low or too high, the projector produces an error message.
When the DMD temperature is too low:
• Lower than 0°C, warning is displayed on th
e LCD panel and yellow warning LED is on. Both remains until the temperature is
above 10°C.
• Between 0°C and 10°C, projector starts up normally with a warning on the LCD panel and the yellow warning LED lights up,
but only for 10 minutes. When the temperature is then not above 10°C the projector goes in standby.
When the DMD temperature is too high:
• When temperature is between 60°C and 65°C, the lamp mode will be reduced from 4 lamps to 2 lamps or 1 lamp.
• When temperature is higher than 65°C, the projector switches to standby.
For a list of possible error codes, see "Error codes", page 205.
6.3.3 Switching to standby
How to switch to standby?
1. Press Standby to switch the projector to standby.
A cool-down counter (after cooling) starts counting down for 5 minutes (only visible on the local LCD panel). During this period
the fans are still running.
A restart is possible during this period.
46
R59770057 CLM HD8 15/03/2010
