S1C63000 CORE CPU MANUAL EPSON 77
CHAPTER 4: INSTRUCTION SET
AND [%ir],imm4 Logical AND of immediate data imm4 and location [ir reg.] 2 cycles
Function: [ir] ← [ir] ∧ imm4
Performs a logical AND operation of the 4-bit immediate data imm4 and the content of the
data memory addressed by the ir register (X or Y), and stores the result in that address.
Code:
Mnemonic MSB LSB
AND [%X],imm4 110100000i3i2i1i01A00H–1A0FH
AND [%Y],imm4 110100010i3i2i1i01A20H–1A2FH
Flags: EICZ
↓ ––↕
Mode: Src: Immediate data
Dst: Register indirect
Extended addressing: Valid
Extended LDB %EXT,imm8
operation: AND [%X],imm4 [00imm8] ← [00imm8] ∧ imm4 (00imm8 = 0000H + 00H to FFH)
LDB %EXT,imm8
AND [%Y],imm4 [FFimm8] ← [FFimm8] ∧ imm4 (FFimm8 = FF00H + 00H to FFH)
AND [%ir]+,imm4
Logical AND of immediate data imm4 and location [ir reg.] and increment ir reg. 2 cycles
Function: [ir] ← [ir] ∧ imm4, ir ← ir + 1
Performs a logical AND operation of the 4-bit immediate data imm4 and the content of the
data memory addressed by the ir register (X or Y), and stores the result in that address. Then
increments the ir register (X or Y). The flags change due to the operation result of the data
memory and the increment result of the ir register does not affect the flags.
Code:
Mnemonic MSB LSB
AND [%X]+,imm4 110100001i3i2i1i01A10H–1A1FH
AND [%Y]+,imm4 110100011i3i2i1i01A30H–1A3FH
Flags: EICZ
↓ ––↕
Mode: Src: Immediate data
Dst: Register indirect
Extended addressing: Invalid
