Faxing
5
bizhub 160f 5-3
5Faxing
This machine is a G3 fax. Faxes can only be sent or received with this ma-
chine if the recipient’s or sender’s machine complies with the G3 standard.
5.1 Dialing
The recipient’s fax number can be dialed using any of the seven different di-
aling methods described below.
The procedures described below assume that the fax is being sent using the
automatic document feeder.
Using direct dialing to communicate with overseas destinations
If the country code and destination number are entered after the international
code, you may hear a busy tone during dialing and transmission may not be
possible. In such cases, press the [Redial/Pause] key twice after entering the
international code to insert an approx. -6-second pause, and then enter the
rest of the number. If this still fails to connect the call, perform manual trans-
mission (p. 6-6).
To fax by entering the fax number directly using the 10-key pad
1 Press the [Fax] key to enter fax mode.
2 Load the document into the automatic document feeder.
3 If necessary, change the resolution setting (p. 5-14).
4 Using the 10-key pad, enter the fax
number of the recipient. F codes
(SUB and SID) can also be entered.
For details, refer to “Using F codes”
on page 6-27.
?
Have you entered the number correctly?
% The fax number can contain a maximum of 30 digits.
% The keys that can be used to enter the fax number are: the number
keys (0 through 9), 1, #, Space, and Pause
% If the [Redial/Pause] key is pressed while entering the fax number,
a 3-second pause is added. A pause appears as “P” in the display.
% If you wish to change the fax number, press the [No/C] key, and
then enter the correct number.
