controls of the original amplifier that was modeled for GearBox. These are shown as three-
dimensional knobs in the main part of the amp panel, like Drive, Tone and Volume on the Small
Tweed panel above.
“Bonus” Knobs –• Some Amp Models also have additional tone controls that weren’t on the
original amp that was studied to create the model. These knobs are shown on a “display” at the
right side of the Amp Panel, like Bass, Treble and Presence on the Small Tweed panel above.
Point your mouse at any of these controls and look in the Info Bar at the bottom of the GuitarPort
window to see a description of the control and its use, then give it a spin and try it out!
The selection of Amp, Cab and Effect Models, as well as the setting of all the amp and effect controls
are saved when you save a Tone. Selecting a Tone from the Tone menu at the top left of the GearBox
window will set all these controls to match the settings that were saved for that Tone.
p Return to What Is Topics
What is ASIO
®
?
ASIO
®
is a protocol for computer audio that allows audio software to communicate with audio
hardware. It is a feature available on many recording programs, which use ASIO
®
to communicate with
a soundcard or other audio device. Line 6 TonePort, GuitarPort, POD X3 and PODxt devices come
with ASIO
®
drivers for Windows
®
- these drivers are installed when you run the GearBox application
installer, or can be downloaded individually from the Line 6 Support - Software Downloads page.
ASIO
®
was designed with the assumption that a single soundcard would provide input and output to
your audio software application. When you choose set your audio software to use the ASIO driver for
your Line 6 device, it will act as that single soundcard. Your guitar (or whatever you are plugging into
your Line 6 hardware’s input) will feed into your computer through your Line 6 hardware, and your
recording program will play back through this hardware’s outputs, and not through other soundcards’
outputs on your computer.
ASIO
®
also provides better performance on Windows
®
systems since it allows the input signal that is
fed into the soundcard travel through the computer, your audio software, and back out the soundcard
outputs in a very short amount of time. This is what is referred to as “low latency” operation. Please see
your Windows
®
recording program’s instructions for details on ASIO
®
operation.
Note - Line 6 hardware utilizes ASIO
®
drivers for Windows
®
systems only. For Mac
®
computers, Line
6 hardware uses the Core Audio driver, which also offers low latency operation, and is the driver
format compatible with most popular Mac
®
audio software.
