The underlining indicates the factory setting.
[[
100 SEARCH ENA
0000
0001
DIAL
KEY
This selects the direct search operation.
0: Direct search mode
1: Non-direct search mode (search dial operations are
acknowledged only in the STILL mode).
102 FF. REW MAX
0000
0001
0002
x16
x32
x50
This selects the maximum speed of fast forwarding and rewinding.
0: 16 times normal speed
1: 32 times normal speed
2: 50 times normal speed
101 SHTL MAX
0000
0001
0002
x8.4
x16
x32
This selects the maximum speed in the shuttle mode.
0: 84 times normal speed
1: 16 times normal speed
2: 32 times normal speed
107 PLAY DELAY 0000
0005
0015
0 (VTR1)
5 (VTR2)
15
This selects the PLAY mode startup time in frame increments.
<Note>
When VTR1 and VTR2 are connected to external components
and controlled from them, set the same PLAY DELAY value for
the whole system.
[[
109 AUTO REW
0000
0001
OFF
ON
This selects the processing to be conducted when the tape end
has been detected.
0: The tape is stopped when it comes to the end.
1: The tape is rewound to its start.
[[
103 AUDIO MUTE
0000
0001
OFF
ON
This selects the status to be established until the audio signals are
output when the unit has transferred from the STOP mode or
search mode to the PLAY mode.
0: The time taken until the audio signals are output is reduced.
1: The audio signals are output after the mode transfer has been
completed.
[[
106 EE MODE SEL
0000
0001
NORMAL
THRU
This selects the output signals in the E-E mode.
0: The signals, which have been delayed by the time taken to
process them internally, are output.
1: The signals are not internally processed and output in their
original form without a delay.
<Notes>
O
“0: NORMAL” is forcibly selected when assemble or insert
editing mode has been selected even with internal connections
(INT mode) or even in the EXT/SEPARATE mode.
O
The “THRU” mode is always set for VTR1.
[
[
[[
108 CAP. LOCK
0000
0001
4F
8F
This selects the CAPSTAN LOCK mode when the SYNCHRO
switch has been set to CF.
0: 4F mode
1: 8F mode
<Note>
In the 525i mode, this setup menu item does not appear.
[
Item Setting
No.
Superimposed
display
No.
Superimposed
display
Description of setting
V
T
R
1
V
T
R
2
33
Setup menus
OPERATION menu
