Specifications
[INPUT/OUTPUT CONNECTORS]
$
VIDEO
Analog component input:
BNC
a
6 ([Y/P
B
/P
R
]
a
2) (VTR1, VTR2)
Y: 1.0 V [P-P], 75 Ω, switched with
analog composite input
P
B
/P
R
: 0.525/0.757 V [P-P] switching, 75 Ω
(75% color bar, 0% setup)
Analog composite input:
BNC
a
2 (VTR1, VTR2), 1.0 V [P-P], 75 Ω,
switched with analog component Y input
Reference input:
BNC
a
2 (loop-through), 75 Ω, automatic
ON/OFF switching
Serial component digital input:
BNC
a
2 (active through), compliant with
SMPTE259M-C standard
Analog component output:
BNC
a
6 ([Y/P
B
/P
R
]
a
2) (VTR1, VTR2)
Y: 1.0 V [P-P], 75 Ω, switched with
analog composite output
P
B
/P
R
: 0.525/0.757 V [P-P] switching, 75 Ω
(75% color bar, 0% setup)
Analog composite output:
BNC
a
2 (VTR1, VTR2), 1.0 V [P-P], 75 Ω,
switched with analog component Y output
Monitor output:
BNC
a
2 (VTR1, VTR2), analog composite,
1.0 V [P-P], 75 Ω, superimpose ON/OFF
Serial component digital output:
BNC
a
1, compliant with SMPTE259M-C
standard
$
AUDIO
Analog input:
XLR
a
4 (VTR1 CH1/2 and VTR2 CH1/2, VTR1
CH1/2/3/4, VTR2 CH1/2/3/4 selectable)
600 Ω/high impedance selectable
+4/0/–3/–20 dBu selectable
VTR2 CH2 input (no.2 connector) only
+4/0/–3/–60 dBu selectable
Serial digital input:
BNC
a
2 (active through), compliant with
SMPTE259M-C standard
Analog output:
XLR
a
4 (VTR1 CH1/2 and VTR2 CH1/2, VTR1
CH1/2/3/4, VTR2 CH1/2/3/4 selectable),
low impedance,
+4/0/–3/–20 dBm selectable (with 600 Ω load)
Monitor output:
XLR
a
2 (L/R or VTR1/2), low impedance, 0 dBu
Serial digital output:
BNC
a
1, compliant with SMPTE259M-C
standard
Headphones:
M3 stereo, variable level (max. –25 dBu), 8 Ω,
VTR1/VTR2 selectable, L/STEREO/R selectable
$
OTHER
TC input:
BNC
a
1, 0.5 to 8 V [P-P], 10 kΩ
TC output:
BNC
a
2 (VTR1, VTR2, video monitor output
connectors selectable), 2.0 V [P-P], 75 Ω
Remote: (525i mode only)
D-sub 9-pin
a
2 (VTR1, VTR2)
RS-422A interface
REMOTE IN/OUT selectable for VTR1
REMOTE IN only for VTR2
EDL input/output:
D-sub 9-pin, RS-232C interface
