1 Hardware Overview 1.10 TFT Color Display
1-30 TECRA M1 Maintenance Manual (960-436)
Table 1-7 LCD module specifications (2/2)
Specifications
Item
14.1-inch SXGA+ TFT (VF2074P01)
Number of Dots 1,400 (W) x 1,050 (H)
Dot spacing (mm) 0.204 (H) x 0.204 (V)
Display range (mm) 285.6 (H) x 214.2 (V)
1.10.2 FL Inverter Board
The FL inverter board supplies a high frequency current to illuminate the LCD module FL. Table 1-
8 lists the FL inverter board specifications.
Table 1-8 FL inverter board specifications
Item Specifications
Voltage (V) DC 5 Input
Power (W) 7
Voltage (V) 750
Current (mA) 6.00
Output
Power (mA) 5W/7VA
