Page xxiPREFACE
Warnings
Cables
Use only AGILE 6287 ULTRA interface cables. Due to the unique design
of the ULTRA input and output ports, ordinary cables will not work and
may cause damage to the equipment.
Shock
Never open the ULTRA when the power is on or when it is connected to
any power source. Opening the ULTRA may void the warranty.
Notes
Standard Factory Setup
Unless otherwise requested, The ULTRA is shipped with the following
defaults:
Parallel output
ASCII character set
Right margin set to column 132
All dip switches in the OFF (up) position
All menu items set to defaults
If the users equipment does not match these parameters, these
configuration settings on the ULTRA must be changed.
Serial Port Setup
With serial interfacing, the baud rate and parity settings of the ULTRA
must match the serial port settings of the printer and alternate host (if using
an alternate host). Baud rates and parity are selected using the dip switches
on the ULTRA back panel. Parity settings also determine the start bits, stop
bits and word length (data bits) of the serial ports.
The ULTRA supports both XON/XOFF (software) and RTS/CTS
(hardware) handshaking protocols. If the users equipment also supports
both handshaking protocols, one of the handshaking methods must be
disabled on the users device.
