Page 1-7INTRODUCTION
HOLD PRINT
This button activates the HOLD PRINT Status Indicator Light on the front
panel of the ULTRA and puts the ULTRA in HOLD PRINT mode. No data
will be output to the printer, and the host will see the printer as busy.
The HOLD PRINT button enables all Operator Function Buttons other than
RESET and TEST.
To exit HOLD PRINT mode, use the ENABLE PRINT button.
TEST
This button sends a General Configuration Report to the printer, if the
ULTRA is in normal operating mode. This report also indicates the current
firmware level.
The TEST button can also be used to output a Printer Test when dip switch
A2 is in the ON (down) position and subsequently either the RESET button
is pressed or the unit is powered up. Refer to Section 4 Troubleshooting
for more information on printing reports.
CANCEL
In SCS mode, this button sends a cancel message to the control unit. If not
in SCS mode, this button is ignored, except when used in conjunction with
the RESET button as noted below.
The HOLD PRINT button must be pressed before using CANCEL.
ENABLE PRINT must be pressed after CANCEL to resume printing.
When dip switch B7 is in the ON (down) position, pressing the RESET and
CANCEL buttons will cause the ULTRA to output a Translate Table
Report. Refer to Section 4 Troubleshooting for more information on
printing reports.
FORM FEED
This button outputs one form feed command to the printer.
The HOLD PRINT button must be pressed before using FORM FEED.
ENABLE PRINT must be pressed after FORM FEED to resume printing.
ENABLE PRINT
When in HOLD PRINT mode, this button turns off the HOLD PRINT
Status Indicator Light on the front panel, exits HOLD PRINT mode and
allows printing to resume.
