Rx Message Registers
The following table shows RxMessage registers. See the complete register table at the start of
this section.
Table 5-14. RxMessage:ID28
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
OFFSET 30h
FIELD ID28 ID27 ID26 ID25 ID24 ID23 ID22 ID21 ID20 ID19 ID18 ID17 ID16 ID15 ID14 ID13
RESET 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Table 5-15. Rx Message: ID28 Register Definitions
Bits Field Name Description
15:0 ID[28:13]
Message Identifier for Both Standard and Extended Messages
Standard messages use ID_28 .. ID_18; ID-17 set to ‘1’.
Table 5-16. RxMessage:ID12
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
OFFSET 32h
FIELD ID12 ID11 ID10 ID09 ID08 ID07 ID06 ID05 ID04 ID03 ID02 ID01 ID00 ///
RESET 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Table 5-17. Rx Message: ID12 Register Definitions
Bits Field Name Description
15:3 ID[12:00]
Message Identifier for Both Standard and Extended Messages
2:0 ///
Reserved
Table 5-18. Rx Message: Data 55
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
OFFSET 34h
FIELD D55 D54 D53 D52 D51 D50 D49 D48 D63 D62 D61 D60 D59 D58 D57 D56
RESET 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Table 5-19. Rx Message: Data 55 Register Definitions
Bits Field Name Description
15:0 D[55:56]
Message Data
Byte 1 is D_63, D_56; Byte 2 is D_55, D_48; and so on.
