Section 6 DLP-5 TRACER 6000 Series Integrated System Manual
104 Copyright © 2005 ADTRAN, Inc. 612806420L1-1F
1. Connect to the TRACER 64x0 using the 10/100BaseT/TX MGMT interface.
If you are not already connected to the unit’s 10/100BaseT/TX MGMT port using Telnet client
software, use the procedure in DLP-3, Setting IP Parameters for the TRACER 64x0, on page 95 to
connect to the unit.
2. Press m to go to the Main menu page.
3. Select the M
ANAGEMENT/UTILITIES menu and press <Enter>.
4. Select the F
IRMWARE UPGRADE UTILITY menu and press <Enter>.
5. Go to the F
ILE XFER METHOD menu and select TFTP. The TRACER 64x0 can use a TFTP server
connected to the same Ethernet network as the local unit or a TFTP server connected to the same
Ethernet network as the remote unit. Make the appropriate selection for your setup (choices are
TFTP-L
OCAL MGMT PORT or TFTP-REMOTE MGMT PORT).
6. Go to the TFTP S
ERVER field and enter the IP address of the network TFTP server.
7. Go to the TFTP F
ILENAME field and enter the filename of the firmware. TRACER 64x0 firmware files
have a .bin extension. When specifying the filename, include the full path if the firmware file is not
located in the TFTP default location. For example, to use a firmware file in the c:\firmware folder on
your local machine, enter c:\firmware\myfirmware.bin into the TFTP F
ILENAME field.
8. Select the U
PGRADE DESTINATION. Using TFTP provides the capability to upgrade both sections of the
local and remote units. Valid choices are L
OCAL IDU and REMOTE IDU.
9. View C
URRENT UPDATE STATUS to verify the progress of the current firmware update or to identify any
errors encountered during the download.
During the TFTP upload, the following status messages display in C
URRENT UPDATE STATUS to
indicate the progress of the upload:
Perform the following steps in the order listed.
I
DLE No active firmware upgrade.
IDU R
ESET Indicates the firmware file transfer to the IDU is complete and the
system is rebooting to load the new firmware.
U
PGRADE ABORTED Indicates the firmware upgrade was manually aborted by selecting
A
BORT from the COMMAND field.
CONTACTING TFTP SERVER Indicates communication with the TFTP network server is trying to be
established with the specified server address in the TFTP S
ERVER IP
A
DDRESS field.
R
EQUESTING TFTP OF
F
ILENAME
Indicates the TRACER 64x0 is requesting TFTP access to the given
update filename and path. Please verify appropriate user rights are
selected for the specified path.
TFTP T
RANSFER IN
P
ROGRESS
Indicates communication with the TFTP network server has been
established and the update file is being transferred between the
TRACER 64x0 and the TFTP network server.
U
PGRADE IMAGE IS VALID Indicates that the system image was verified as a valid image for
the specified update. Before the firmware upgrade begins, the
TRACER 64x0 verifies that the image is valid. If it is not valid for the
system, U
PGRADE IMAGE IS INVALID displays.
