2 - 8
ASSEMBLY AND CONNECTIONS
6
Slide the paper cassette into
the MFC until it locks into
place.
7
Pull out the paper output tray
extension.
Connecting the MFC
1
Connect the power cord.
There is no ON/OFF switch. When you
plug in the power cord, the power goes
on and the LCD alternately shows:
2
Connect the telephone line cord.
Connect one end of the telephone line cord to the jack on the MFC and the other
end to a modular wall jack.
WARNING
■ The MFC must be grounded using a 3-prong plug.
■ Since the MFC is grounded through the power outlet, protect yourself from potentially
hazardous electrical conditions on the telephone line by keeping the MFC’s power
turned on when you connect it to a telephone line. When you want to move your MFC,
protect yourself by disconnecting the telephone line first, and then the power cord.
Caution
Operating the MFC before you install the ink cartridges will permanently
damage the print head.
Paper Output Tray Extension
Telephone
Line Cord
Power Cord
SET CARTRIDGES
PLS OPEN COVER
