114
CHAPTER 2 DEPENDENCE FUNCTIONS
2.2.8.6 Specify Displaying Trace Data Start
It is possible to specify from which data in the trace buffer to display. To do so, specify a
frame number with the SHOW TRACE command in the single trace mode, or specify
either a global number, or a block number and local number with the SHOW MULTITRACE
command in the multi trace mode. A range can also be specified.
■ Specifying Displaying Trace Data Start
It is possible to specify from which data in the trace buffer to displays. To do this, specify a frame number
with the SHOW TRACE command in the single trace, and specify either a global number, or a block number
and local number with the SHOW MULTITRACE command in the multi trace. A range can also be
specified.
[Example]
- In Single Trace Mode
>SHOW TRACE/CYCLE -6 : Start displaying from frame -6
>SHOW TRACE/CYCLE -6..10 : Display from frame -6 to frame 10
>SHOW TRACE -6 : Start displaying from step -6
>SHOW TRACE -6..10 : Displays from step -6 to step 10
Note:
A step number can only be specified when the MCU execution mode is set to the debugging mode.
- In Multi trace
>SHOW MULTITRACE/GLOBAL 500 : Start displaying from frame 500 (Global number)
>SHOW MULTITRACE/LOCAL 2 : Displaying block number 2
>SHOW MULTITRACE/LOCAL 2,-5..5 : Display from frame -5 to frame 5 of block number 2
