PC Configuration
Before you can make a PPP connection using IPX with Windows 95, you must
configure your PC as follows:
Install the following Client, Adapter, and Protocol software (included with
Windows 95):
— Client Software for NetWare Networks (currently R3.X only)
— Protocol Software for IPX (and IP if desired)
— Dial-up Adapter Software.
To install the software, select Control Panel, then click on Network.
Click on the Add button to display the Select Network Component Type.
Select Client, Adapter, and Protocol in turn to add the software needed.
Once this software has been installed, you must configure the properties
for your particular configuration. To do so, click on Properties in the Net-
work window. Refer to the Windows 95 on-line help screens for details.
Establish the PPP connection as follows (refer to Figures F-1 and F-2):
1 . Click on the Dial Up Networking icon (Figure F-1, left) to display
the Dial Up Networking window (Figure F-1, right).
2 . From this window, select the Make New Connection icon to enter
the connection parameters. Once you have entered the connection
parameters, the system will save them with a name you select and
place an icon with that name in the Dial Up Networking window.
The next time you want to make the same connection, you need
only click on that icon.
Note: When defining the connection parameters for your system,
select Display Terminal Window after dialup.
3 . Once you have entered the connection parameters, a Connect to
window will be displayed. Enter the appropriate information. This
will open a Terminal Window in which you can authenticate and
enter the data switch dialstring for the LCS60.
Issue 3 F-7
