The LEDs labeled Status LED in Figure 5 on page 12 and Figure 6 on page 12 indicate the
status of one of the four port parameters—speed, duplex mode, administrative status,
and Power over Ethernet (PoE) status. Use the mode button below the POE LED on the
far right side of the front panel to toggle the Status LED to show the different port
parameters. Youcan tell which port parameter is indicated by the Status LED by seeing
which port status mode LED (SPD, DX, EN, and POE) is lit. (See Figure 6 on page 12).
Table 6 on page 13 describes the Status LED.
Table 6: Status LED on the Network Ports and Uplink Ports in EX2200 Switches
Stateand DescriptionPortParameters
Indicatesthe speed.The speedindicators fornetworkports are:
•
One blink per second—10Mbps
•
Two blinksper second—100 Mbps
•
Three blinksper second—1000 Mbps
Thespeed indicatorsforuplink ports are:
•
On steadily—1000Mbps
•
Off—10/100 Mbps
Speed
Indicatesthe duplexmode. Thestatusindicators are:
•
On steadily—Portis set tofull-duplexmode.
•
Off—Port is setto half-duplexmode.
Duplex mode
Indicatesthe administrative status. Thestatusindicators are:
•
On steadily—Portis administrativelyenabled.
•
Off—Port is administratively disabled.
Administrative status
Indicatesthe PoEstatus.The statusindicatorsfor network ports are:
•
Onsteadily—PoEisavailableontheport,adevicethatdrawspowerfromtheport
is connectedto the port, and the deviceis drawing powerfrom the port.
•
Blinking—PoEisavailableontheport,butnopowerisdrawnfromtheportbecause
of one of the following:
•
No devicethatdraws powerfromthe port is connected to the port.
•
Adevicethatdrawspowerfromtheportisconnectedtotheport,butthedevice
is not drawing any power from the port.
•
Off—PoE is not availableon the port.
PoEisnotavailableonuplinkports;therefore,theLEDforthoseportsisalwaysunlit.
PoEstatus
You can tell which port parameter is indicated by the Status LED on network ports and
uplink ports by issuing the operational mode command show chassis led.
Related
Documentation
Front Panel of an EX2200 Switch on page 5•
• Configuring Gigabit Ethernet Interfaces (CLI Procedure)
• Configuring Gigabit Ethernet Interfaces (J-WebProcedure)
13Copyright©2010, JuniperNetworks, Inc.
