Inside the Notebook (Figure 1.6)
Your WinBook notebook comes equipped with two high-quality
Integrated Stereo Speakers. These are located on the left and right
edges of the system just above the keyboard.
Status LED Indicator Panel from left to right (Figure 1.7).
The Hard Drive Access LED: A green light indicates
that the computer is reading from the hard drive.
The CD-ROM Drive Access LED: A green light indi-
cates that the computer is reading from the CD-
ROM or DVD drive.
Num Lock: A green light indicates that the Num Lock
function has been activated. The embedded number pad
will be enabled.
Caps Lock: A green light indicates that the CapsLock
function has been activated.
Scroll Lock: A green light indicates that the Scroll Lock
function has been activated. In certain programs,
this will prevent the screen from scrolling.
The Power Button for your system
is located just above the keyboard
and the LED indicators. You can
adjust the function of the power
button in the Power Properties
window (double-click on the
Power icon in the Control Panel).
1.9
Chapter 1: Getting Started
Figure 1.6: Inside
the Notebook
Power
Button
Power & Battery
Charging LEDs
Integrated
Stereo
Speakers
Microphone
