Prestige 782R G.SHDSL Router
IP Routing Policy Setup 11-9
Figure 11-8 IP Policy Routing
Step 6. Check Menu 25.1 - IP Routing Policy Setup to see if the rule is added correctly.
Step 7. Apply both policy sets in Menu 3.2 as shown next.
Figure 11-9 Applying IP Policies
Menu 3.2 - TCP/IP and DHCP Ethernet Setup
DHCP Setup
DHCP= Server
Client IP Pool Starting Address= 192.168.1.33
Size of Client IP Pool= 64
Primary DNS Server= 0.0.0.0
Secondary DNS Server= 0.0.0.0
Remote DHCP Server= N/A
TCP/IP Setup:
IP Address= 192.168.1.1
IP Subnet Mask= 255.255.255.0
RIP Direction= Both
Version= RIP-1
Multicast= None
IP Policies= 1,2
Edit IP Alias= No
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
Menu 25.2 - IP Routing Policy
Policy Set Name= set2
Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Don't Care Packet length= 10
Precedence = Don't Care Len Comp= N/A
Source:
addr start= 0.0.0.0 end= N/A
port start= 0 end= N/A
Destination:
addr start= 0.0.0.0 end= N/A
port start= 20 end= 21
Action= Matched
Gateway addr =192.168.1.100 Log= No
Type of Service= No Change
Precedence = No Change
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
