Prestige 782R G.SHDSL Router
5-2 Remote Node TCP/IP Configuration
LLC-based Multiplexing or PPP Encapsulation
For LLC-based multiplexing or PPP encapsulation, one VC carries multiple protocols with protocol
identifying information being contained in each packet header.
Figure 5-2 Menu 11.6 for LLC-based Multiplexing or PPP Encapsulation
In this case, only one set of VPI and VCI numbers need be specified for all protocols. The valid range for
the VPI is 0 to 255 and for the VCI is 32 to 65535 (1 to 31 is reserved for local management of ATM
traffic).
The following diagram explains the sample IP addresses to help you understand the field of My Wan Addr
in Menu 11.3. Refer to a previous figure “LAN and WAN IPs” for a brief review of what a WAN IP is. My
WAN Addr indicates the local Prestige WAN IP while Rem IP Addr indicates the peer WAN IP.
Menu 11.6 - Remote Node ATM Layer Options
VPI/VCI (LLC-Multiplexing or PPP-Encapsulation)
VPI #= 0
VCI #= 38
Peak Cell Rate (cell/sec)= 5500
Sustain Cell Rate (cell/sec)= 0
Maximum Burst Size (cell)= 0
ENTER here to CONFIRM or ESC to CANCEL:
.
Only one set of
VPI and VCI
numbers needs to
be specified.
