Chapter 5 Parts Lists
5-23 CL-S700/CL-S703
PARTS LIST for CL-S700/CL-S703 TITLE: Unit, Frame Rear Sheet No. 1/1
Drawing No. 5 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
5-1 Bushing JE99704-0 1 24400670
5-2 Ribbon Guide Roller E JE99710-0 1 25100710
5-3 Bushing JE99705-0 5 24400680
5-4 SA, Frame Rear JN44705-0 1
5-5 Rear Arm Spring JE99650-0 1 21903231
5-6 SA, Plate Stopper Rear JN44708-0 1
5-7 Side Plate L JE99639-0 1 20804850
5-8 Ribbon Guide Roller C JE99709-0 2 25100690
5-9 Beam JE99667-0 1 23000680
5-10 Side Plate R JE99640-0 1 20804860
5-11 Screw, PH (SW+PW), M3.0x5 E04030-050F 1
5-12 Screw, FT, M3.0x6 E00230-060F 4
