MIL-3000FTX Series of FastPort Print Servers C-5
5. Use an ASCII editor to prepare the following config. file:
SIMBA:QUEUEP:PS1:Parallel1::ss=”M-%-12345X@PJL enter
language = PostScript \r\n”,es=”M-%-12345X@PJL enter
language = pcl \r\n”,b=ps,cd
Or use the ACT menus:
1. Select the Advanced Configuration form the “Configure” menu.
2. Select Netware Configuration and Configure Queue.
3. Scroll down the list of printers and select one.
4. Scroll down the list of file servers and select one.
5. Scroll down the list of Queues and select one.
6. From the Queue Options menu, select Startstrings. The start string:
<Esc>%-12345X@PJL enter language = PostScript.
7. Add the end string <Esc>%-12345X@PJL enter language = pcl
to change the mode back to PCL.
8. To complete the configuration, select Send Control+D and select
PostScript from the choice Banner page.
C.2.1.5Example 2
The second queue on server SOAVE has a configuration file that puts an
HP LaserJet into PCL mode, sends the file without the banner (b=off), and
puts the printer back into PS mode. In plain text form that looks like this:
SOAVE:QUEUEP:PS:Parallel1:ss=”M-%-12345X@PJL enter
language = pcl\r\n”,es=”M-%-12345X@PJL enter language
= PostScript \r\n”,b=off
Configuration has info. about devices connected to FastPort.
C.2.2 Print Server Configuration
The Print Server Configuration menu allows a user to view print server
information, including network name, model number, and ROM version
(refer to Table C-1). Parameters that can be changed, including:
• Assign IP addresses for both FastPort and hosts that print to FastPort
• Set serial and parallel port parameters
