Parts Index
Description Part No. Fig. Ref.
AC Cable Cover RB1-7344-000CN 8-5 3
Back Cover RB1-7333-000CN 8-2 3
Back Grounding Clip RB1-7199-000CN 8-7 7
Back Sheet Metal RF5-1509-000CN 8-5 4
Cap RB1-7234-000CN 8-5 7
Cap RB1-7302-000CN 8-5 8
Case Grounding Metal RB1-7129-000CN 8-4 8
Clutch RB1-7197-000CN 8-7 6
Control Panel Cable Guide RB1-7343-000CN 8-5 5
Control Panel PCA Assembly RG5-2028-000CN 8-4 22
DC Controller PCA (110v) RG5-2023-000CN 8-6 3
DC Controller PCA (110V) Exchange C3941-69001 8-6 3
DC Controller PCA (220v) RG5-2025-000CN 8-6 3
DC Controller PCA (220V) Exchange C3941-69002 8-6 3
DC Controller PCA Case Assembly RG5-2022-000CN 8-6 4
DC Controller PCA/Formatter Cable RG5-2036-000CN 8-6 5
Delivery Assembly RG5-2012-000CN 8-10
Delivery Roller #1 RB1-7284-000CN 8-10 1
Delivery Roller #2 RB1-7285-000CN 8-10 2
Delivery Spring #1 RB1-7286-000CN 8-10 3
Delivery Spring #2 RB1-7287-000CN 8-10 4
Door Sensor Cable RG5-2031-000CN 8-6 9
Door Switch Cable RG5-2037-000CN 8-6 14
EP Door Assembly RF5-1501-000CN 8-2 8
EP Door Chmny RB1-7327-000CN 8-2 6
EP Left Hand Guide RF5-1514-000CN 8-4 10
EP Right Hand Guide #1 RF5-1515-000CN 8-4 9
EP Right Hand Guide #2 RB1-7341-000CN 8-4 3
Exit Roller RF5-1521-000CN 8-3 17
Exit Roller Bushing RB1-7288-000CN 8-3 2
Face-up/Face-down Shaft RB1-7276-000CN 8-9 2
Face-up/Face-down Switch RB1-7278-000CN 8-2 4A
Table A-1 Alphabetical Parts List
A-2 Parts Index
