Protocols — Console Support
Version 1.10 12/01/02 10-47
Related Definitions
//*******************************************************
// EFI_SIMPLE_POINTER_MODE
//*******************************************************
typedef struct {
UINT64 ResolutionX;
UINT64 ResolutionY;
UINT64 ResolutionZ;
BOOLEAN LeftButton;
BOOLEAN RightButton;
} EFI_SIMPLE_POINTER_MODE;
The following data values in the EFI_SIMPLE_POINTER_MODE interface are read-only and are
changed by using the appropriate interface functions:
ResolutionX The resolution of the pointer device on the x-axis in counts/mm. If 0,
then the pointer device does not support an x-axis.
ResolutionY The resolution of the pointer device on the y-axis in counts/mm. If 0,
then the pointer device does not support a y-axis.
ResolutionZ The resolution of the pointer device on the z-axis in counts/mm. If 0,
then the pointer device does not support a z-axis.
LeftButton TRUE if a left button is present on the pointer device. Otherwise FALSE.
RightButton TRUE if a right button is present on the pointer device. Otherwise
FALSE.
Description
The EFI_SIMPLE_POINTER_PROTOCOL provides a set of services for a pointer device that
can use used as an input device from an EFI application. The services include the ability to reset
the pointer device, retrieve get the state of the pointer device, and retrieve the capabilities of the
pointer device.
