Protocols — PCI Bus Support
Version 1.10 12/01/02 12-69
EFI_PCI_IO_PROTOCOL.Mem.Read()
EFI_PCI_IO_PROTOCOL.Mem.Write()
Summary
Enable a PCI driver to access PCI controller registers in the PCI memory space.
Prototype
typedef
EFI_STATUS
(EFIAPI *EFI_PCI_IO_PROTOCOL_MEM) (
IN EFI_PCI_IO_PROTOCOL *This,
IN EFI_PCI_IO_PROTOCOL_WIDTH Width,
IN UINT8 BarIndex,
IN UINT64 Offset,
IN UINTN Count,
IN OUT VOID *Buffer
);
Parameters
This A pointer to the EFI_PCI_IO_PROTOCOL instance. Type
EFI_PCI_IO_PROTOCOL is defined in Section 12.4.
Width Signifies the width of the memory operations. Type
EFI_PCI_IO_PROTOCOL_WIDTH
is defined in Section 12.4.
BarIndex The BAR index of the standard PCI Configuration header to use as
the base address for the memory operation to perform. This allows
all drivers to use BAR relative addressing. The legal range for this
field is 0..5. However, the value
EFI_PCI_IO_PASS_THROUGH_BAR
can be used to bypass the
BAR relative addressing and pass Offset to the PCI Root Bridge
I/O Protocol unchanged. Type
EFI_PCI_IO_PASS_THROUGH_BAR is defined in Section 12.4.
Offset The offset within the selected BAR to start the memory operation.
Count The number of memory operations to perform. Bytes moved is
Width size * Count, starting at Offset.
Buffer For read operations, the destination buffer to store the results. For
write operations, the source buffer to write data from.
