Extensible Firmware Interface Specification
10-50 12/01/02 Version 1.10
RelativeMovementY The signed distance in counts that the pointer device has been
moved along the y-axis. The actual distance moved is
RelativeMovementY / ResolutionY millimeters. If the
ResolutionY field of the EFI_SIMPLE_POINTER_MODE
structure is 0, then this pointer device does not support a y-axis,
and this field must be ignored.
RelativeMovementZ The signed distance in counts that the pointer device has been
moved along the z-axis. The actual distance moved is
RelativeMovementZ / ResolutionZ millimeters. If the
ResolutionZ field of the EFI_SIMPLE_POINTER_MODE
structure is 0, then this pointer device does not support a z-axis,
and this field must be ignored.
LeftButton If TRUE, then the left button of the pointer device is being
pressed. If FALSE, then the left button of the pointer device is
not being pressed. If the LeftButton field of the
EFI_SIMPLE_POINTER_MODE structure is FALSE, then this
field is not valid, and must be ignored.
RightButton If TRUE, then the right button of the pointer device is being
pressed. If FALSE, then the right button of the pointer device is
not being pressed. If the RightButton field of the
EFI_SIMPLE_POINTER_MODE structure is FALSE, then this
field is not valid, and must be ignored.
Description
The GetState() function retrieves the current state of a pointer device. This includes
information on the buttons associated with the pointer device and the distance that each of the axes
associated with the pointer device has been moved. If the state of the pointer device has not
changed since the last call to GetState(), then EFI_NOT_READY is returned. If the state of the
pointer device has changed since the last call to GetState(), then the state information is placed
in State, and EFI_SUCCESS is returned. If a device error occurs while attempting to retrieve
the state information, then EFI_DEVICE_ERROR is returned.
Status Codes Returned
EFI_SUCCESS
The state of the pointer device was returned in
State.
EFI_NOT_READY The state of the pointer device has not changed since the last call to
GetState().
EFI_DEVICE_ERROR A device error occurred while attempting to retrieve the pointer device’s
current state.
