Firmware Pages and Descriptions
105
7" Modero Widescreen Touch Panels
Sensor Setup
The Sensor Setup page (FIG. 97) allows you to adjust the Light and Motion Sensor parameters on a
Modero touch panel.
The elements of the Sensor Setup page are described in the table below:
FIG. 96 Sample relationship between G4 Web Control and Mange WebControl Connections window
FIG. 97 Sensor Setup page
A light level value between the Minimum and Maximum DIM Mode values delivers an
average light level. The DIM mode Min Level can never exceed the DIM Mode Max
Level.
Sensor Setup Page Elements
Back: Saves the changes and returns you to the previously active touch panel page.
Connection Status icon: This visual display of the connection status allows the user to have a current
visual update of the panel’s connection status regardless of what page is
currently active.
• A Lock only appears on the icon if the panel has established a connection
with a currently secured target Master (requiring a username and password).
