CV7 Touch Panel Accessories
26
7" Modero Widescreen Touch Panels
NXT-BP Power Pack (FG2255-10)
The NXT-BP Power Pack (FIG. 24) is a rechargeable Lithium-Ion "smart" battery used to provide power
to the NXT Modero panel through the NXA-BASE/1 Battery Base. This battery incorporates an
on-board battery life indicator. The NXT-BP battery can be charged through either the base (when
connected to the CV7 panel) or through an optional NXT-CHG Modero Power Station.
Although this product is included within the NXA-BASE/1 Kit (FG2255-05K), extra NXT-BP Power
Packs (FG2255-10) can be purchased separately as an optional accessory.
FIG. 24 NXT-BP Power Pack
NXT-BP Specifications
Dimensions (HWD): • 0.69" x 3.50" x 5.81" (1.75 cm x 8.89 cm x 14.76 cm)
Power (Voltage): • 11.1 Volts (nominal)
Weight: • Single NXT-BP Power Pack: 1.0 lbs (0.45 kg)
Features: • Battery Usage: 4 to 8 hours (time is usage dependant)
• Charge Capacity: 6300mAh
Operating / Storage
Environment:
• Operating Temperature: 0° C (32° F) to 40° C (104° F)
• Operating Humidity: 20% - 85% RH
• Storage/Discharge Temperature: -20° C (-4° F) to 60° C (140° F)
• Storage Humidity: 5% - 85% RH
