7" Modero Widescreen Touch Panels
NXA-CFSP Compact Flash (FG2116-3x)
Every CV7 Modero panel is shipped with a 64 MB Compact Flash card (NXA-CFSP).
The NXA-CFSP Compact Flash card is factory programmed with specific panel firmware and can be
upgraded to several sizes, up to 1GB:
Upgrading the Compact Flash card in both panel typesinvolves opening the panel enclosure/outer
housing to access the internal circuit board, removing the existing card, replacing it with the 802.11g
upgrade, and then resecuring the panel enclosure, as described in the following sections.
NXA-WC80211GCF Specifications (Cont.)
Wireless LAN Security: • EAP-FAST
• EAP-LEAP
•EAP-PEAP
•EAP-TLS
•EAP-TTLS
• WEP 64 & 128
•WPA-PSK
Touch Panel
Compatibility:
• MVP-7500 (FG5965-01)
• MVP-8400 (FG5965-02)
• NXD-CV10 (FG2259-02)
• NXT-CV10 (FG2259-01/03)
• NXD-CV7 (FG2258-02)
• NXT-CV7 (FG2258-01)
Included Accessories: • Double-sided adhesive tape
• Mounting Template cutout (62-2255-04)
• NXA-WC80211GCF Installation Guide
• Two Alcohol cleaning pads
• Wireless CF card with wireless antenna
Other AMX Equipment: • NXA-WAP250G Modero Wireless Access Point (FG2255-50)
• Upgrade Compact Flash memory (factory programmed with firmware):
NXA-CFSP128M - 128 MB compact flash card (FG2116-36)
NXA-CFSP256M - 256 MB compact flash card (FG2116-37)
NXA-CFSP512M - 512 MB compact flash card (FG2116-38)
NXA-CFSP1GB - 1 GB compact flash card (FG2116-39)
If possible, upgrade the panel’s internal components (Compact Flash or wireless
interface cards) prior to installing or using the panel.
Optional Compact Flash Upgrades
• NXA-CV7CF128M - 128 MB Compact Flash card (FG2116-60)
• NXA-CV7CF256M - 256 MB Compact Flash card (FG2116-61)
• NXA-CV7CF512M - 512 MB Compact Flash card (FG2116-62)
• NXA-CV7CF1G - 1 GB Compact Flash card (FG2116-63)
