Introduction
3
7" Modero Widescreen Touch Panels
CV7 Specifications
The following table outlines the specifications for the 7" Widescreen Modero panels.
Specifications for 7" Widescreen Video Touch Panels
Dimensions (HWD): • NXA-RK7: metal rack-mount with black matte finish:
(4 RU - rack units high)
6.97" x 19.0" x 0.50" (17.70 cm x 48.26 cm x 1.27 cm)
• NXT-CV7 (Fully raised): 6.86" x 7.96" x 6.93"
(17.40 cm x 20.20 cm x 17.60 cm)
• NXT-CV7 (Fully lowered): 3.70" x 7.96" x 6.93"
(9.40 cm x 20.20 cm x 17.60 cm)
• NXD-CV7 (with faceplate): 5.93" x 7.87" x 3.28"
(15.06 cm x 20.00 cm x 8.33 cm)
• CB-TP7 Rough-In/Wallbox (optional): 5.47" x 7.23" x 3.40"
(13.90 cm x 18.40 cm x 8.64 cm)
Power Requirements
(stand-alone CV7):
• Constant current draw: 1.0 A @ 12 VDC (stand-alone)
• Startup current draw: 1.5 A @ 12 VDC (stand-alone)
Power Requirements
(CV7 and BASE/1):
• Constant current draw: 2.4 A @ 12 VDC
• Startup current draw: 3.6 A @ 12 VDC
Memory (factory default): • 64 MB SDRAM
• 64 MB Compact Flash (upgradeable to 1 GB - factory programmed)
Weight (stand-alone): • NXD-CV7: 4.12 lbs (1.87 kg)
• NXTCV7: 4.12 lbs (1.87 kg)
Certifications: • FCC Part 15 Class B, CE, and EN 60950
Panel LCD Parameters: • Aspect ratio: 16 x 9
• Brightness (luminance): 350 cd/m
2
• Channel transparency: 8-bit Alpha blending
• Contrast ratio: 200:1
• Display colors: 256 thousand colors (18-bit color depth)
• Dot/pixel pitch: 0.19 mm
• Panel type: TFT Color Active-Matrix
• Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency
• Video format: NTSC, PAL, and SECAM
• Viewing angles (100° total viewing angle):
Vertical: + 50° (up from center) and - 50° (down from center)
Active Screen Area: • 6.00” x 3.60” (15.24cm x 9.14cm)
IR Reception Angle: • Horizontal: +
50° (left and right from center)
•Vertical: +
30° (up and down from center)
Supported Audio Sample
Rates:
• 48000Hz, 44100Hz, 32000Hz, 24000Hz, 22050Hz, 16000Hz, 12000Hz,
11025Hz, and 8000Hz.
