Chapter 6 Troubleshooting and Diagnostics Installation and Operation Manual
6-18 Testing ASMi-52 ASMi-52 Ver. 2.5
ASMi-52
Bert
1. Bert (ON/OFF)
2. Bert + RLB (ON/OFF)
3. Bert pattern >
4. Save Bert parameters
>
ESC-prev. menu ; !–main menu ; &–exit terminal
Figure 6-16. BERT Menu
3. From the Bert menu, select Bert Pattern (see Figure 6-16).
The Bert Pattern selection is displayed (see Figure 6-17).
ASMi-52
Bert Pattern
>
2E15-1
Mark
Spare
Alternate
ESC-prev. menu ; !–main menu ; &–exit terminal
Figure 6-17. BERT Pattern Menu
To configure the BERT results:
1. From the Monitoring menu, select Physical Port Statistics (Main menu >
Monitoring > Physical Port Statistics).
The Physical Port Statistics menu is displayed, (see Figure 6-1.
2. From the Physical Port Statistics menu, select Bert Performance.
The Bert Performance menu is displayed, (see Figure 6-18).
ASMi-52
Bert Performances
1. Bert results
2. Inject single error local
3. Inject single error remote
4. Bert clear local performance
5. Bert clear remote performance
>
ESC-prev. menu; !–main menu ; &–exit terminal
Figure 6-18. Bert Performance Menu
3. From the Bert Performances menu, select Bert Results.
The Bert Result window is displayed, (see Figure 6-19)
