System Status
Local Remote
Device Type (ASMi52_SA_M (PLASTIC)-STU_C-2W)
ASMi52_SA
Clock Source (INT) RCV
Software Version (2.01E24) (2.01E24)
Hardware Version (0.00) (0.00)
FPGA Version (0.13) (0.13)
Hardware Status (NO HARDWARE FAILURE) (NO HW
FAILURE)
PS (WIDE RANGE PS 48-60 VDC/100-240 VAC)
(WIDE RANGE)
MAC address (0 20 D2 20 5F AB) (0 20 D2 21
12)
IP address (172.17.161.73)
(172.17.161.75)
Alarm Indication NORMAL NORMAL
Test Indication (OFF) (OFF)
>
ESC-prev. menu; !-main menu; &-exit;
Figure 4-39. System Status Screen
Alarms are described in Chapter 5.
Displaying the Port Status
To display the port status information:
1. From the Physical Port Status menu, select Port Status (Main menu >
Monitoring > Physical Port Status > Port Status) to display the port status.
The Port Status menu appears (see Figure 4-40).
ASMi-52
Port status
Local Remote
SHDSL (Standard ANNEX_B, Wire mode 2W) ______
SHDSL Line (Status: SYNC, State: DATA mode) ______
Framer Type (SLOTTED E1) ______
EOC compatible (PROPRIETARY) ______
Actual PSD (ASYM_PSD_DISABLE) ______
Line rate (2048 kbps + 8 kbps) ______
E1 interface (IR-G704-E1/BALANCE Data rate: 2048 kbps) ______
HW status (NO HARDWARE FAILURE) ______
Test status (NONE)> ______
Alarm status (NORMAL) ______
REM connected line (1) ______
(N)
ESC-prev. menu; !-main menu; &-exit;
Figure 4-40. Port Status Menu
