Chapter 4 Configuration Installation and Operation Manual
4-24 Configuring the Physical Ports ASMi-52 Ver. 2.5
2. Select the Snext margin by typing the number corresponding to the required
value.
The SHDSL Remote Port menu appears.
3. Select Save to save the changes.
ASMi-52
Snext margin (Disable Snext margin)
1. -10 12. 1
2. -9 13. 2
3. -8 14. 3
4. -7 15. 4
5. -6 16. 5
6. -5 17. 6
7. -4 18. 7
8. -3 19. 8
9. -2 20. 9
10. -1 21. 10
11. 0 22. Disable Snext margin
>
ESC-prev. menu; !-main menu; &-exit; @-scroll
Figure 4-29. Snext Margin Menu
Configuring the Current Margin
The current margin indicates the minimum required target margin for the local line
conditions during the startup sequence. This setting is available only if the rate
adaptation is enabled (see the line probing configuration below).
•
Disabling the current margin parameter allows the use of all line rates, regardless of
the line condition.
To configure the current margin:
1. From the SHDSL Remote Port menu, select Current Margin (Main menu >
Configuration > SHDSL Configuration > SHDSL Remote Port > Current
Margin).
The Current Margin menu appears. The display is identical to the Snext
Margin menu, except for its title (see Figure 4-29).
2. Select the current margin by typing the number corresponding to the required
value, and press <Enter>.
The SHDSL Remote Port menu appears.
3. Select Save to save the changes.
Note
