Installation and Operation Manual Chapter 3 Operation
ASMi-52 Ver. 2.5 Configuration Alternatives 3-11
• Trace – opens an additional pane for system messages, progress indicators
(ping, software and configuration file downloads) and alarms. It is
recommended to keep the trace pane open all the time.
• Refresh All – refreshes all screen elements.
Configuration Menus
The following is the menu map of the ASMi-52 management software.
Some of the management menu options depend on the type of the DTE interface
installed in ASMi-52:
• DTS Configuration (Main menu > Configuration > System Configuration >
Management) is available only for the units with E1 or T1 interface.
• LAN Rate (Main menu > Configuration > LAN Configuration > Local LAN
Configuration) is available for the units with the user’s 10/100BaseT port.
• Data Rate (Main menu > Configuration > DTE Configuration > DTE Remote
Port) is available for the units with a serial DTE interface.
• E1 Configuration (Main menu > Configuration) is available for the units with an
E1 local port.
• Figure 3-10 illustrates software menus of the unit that operates with SHDSL
repeater in the line.
Note
