Chapter 4 Configuration Installation and Operation Manual
4-2 Configuring ASMi-52 for Management ASMi-52 Ver. 2.5
Entering Device Information
The Device Information menu allows you to assign a name to ASMi-52, define its
location, and contact person. These entries may include up to 20 characters.
To enter device information:
1. Display the Sys Contact menu (Main menu > Configuration > System
Configuration > Management > Device Info > Sys Contact) and enter the
name of a contact person.
2. Display the Sys Location menu (Main menu > Configuration > System
Configuration > Management > Device Info > Sys Location) and enter the
description of the ASMi-52 location.
3. Display the Sys Name menu (Main menu > Configuration > System
Configuration > Management > Device Info > Sys Name) and enter the
name of the unit.
4. Press <Esc> to return to the Management menu (see Figure 4-1).
5. From the Management menu, select Save to save your changes.
To clear system parameters:
1. From the Device Info menu, select Clear sys params (Main menu >
Configuration > System Configuration > Management > Device Info > Clear
Sys Params).
ASMi-52 displays the following message:
ASMi-52
Clear sys params
Are you sure !!! Clear (Y/N)
>
ESC-prev. menu; !-main menu; &-exit; @-scroll
Figure 4-2. Clear Sys Params Prompt
2. Type Y to confirm the deletion.
ASMi-52 deletes all device info parameters.
ASMi-52
Device Info
Sys description ASMi-52 SA HW Version: 0.00, SW Version:
2.01E24)
1. Sys contact (sss)
2. Sys location ()
3. Sys name ()
4. Clear sys params
>
ESC-prev. menu; !-main menu; &-exit; @-scroll
Figure 4-3. Device Information Menu
