Chapter 4 Configuration Installation and Operation Manual
4-36 Additional Tasks ASMi-52 Ver. 2.5
4.4 Additional Tasks
Displaying the ASMi-52 Status
The ASMi-52 software allows you to display the modem system and physical port
information.
The status information is available via the Monitoring menu.
To access the Monitoring menu:
• From the Main menu, select Monitoring.
The Monitoring menu appears (see Figure 4-38).
ASMi-52
Monitoring
1. Total Alarms [] >
2. System monitoring >
3. Physical ports status >
4. Physical ports Statistics >
5. Repeater status >
6. Open Virtual Connection
>
ESC-prev. menu; !-main menu; &-exit;
Figure 4-38. Monitoring Menu
Displaying the System Status
To display the system information:
1. From the System Monitoring menu, select System Status (Main menu >
Monitoring >System Monitoring > System Status) to display the device status
information.
The System Status menu appears (see Figure 4-39).
