Chapter 4 Configuration Installation and Operation Manual
4-46 Additional Tasks ASMi-52 Ver. 2.5
Resetting to Default Settings
You can reset the local or remote ASMi-52 to its default settings. Resetting to the
factory default does not affect the master clock setting. In addition, you can reset
the local ASMi-52 without affecting its management parameters (IP address, mask
and default gateway).
To reset ASMi-52 to the factory default:
1. From the System Configuration menu, select Factory Default. (Main menu >
Configuration > System Configuration > Factory Default).
The Factory Default menu is displayed (Figure 4-49).
ASMi-52
Factory default
Remote unit number (1)
1. Local factory default ...
2. Remote factory default ...
3. Local factory default W/O MNG ...
4. Remote factory default W/O MNG ...
>
ESC - prev. menu ; ! – main menu ; & – exit
Figure 4-49. Factory Default Menu
2. From the Factory Default menu, perform one of the following steps:
Select Local Factory Default to reset the local ASMi-52.
Select Remote Factory Default to reset the remote device.
Select Local Factory Default W/O MNG to reset all parameters, except for
the IP address, mask, default gateway and the manager list of the local
ASMi-52.
Select Remote Factory Default W/O MNG to reset all parameters, except
for the IP address, mask, default gateway and the manager list of the
remote ASMi-52.
•
Local/Remote Factory Default W/O MNG parameters are available only for the
units equipped with the management LAN port.
ASMi-52 displays the following message:
Request to factory default !!! Confirm Y/N
3. Type Y to confirm the reset.
ASMi-52 resets all configuration parameters, except for the master clock
(and IP values), to their default settings and restarts the system.
Resetting the ASMi-52 Modem
You can reset the SHDSL interface of the modem or repeater, or perform the
overall reset of the modem.
To reset the SHDSL interface or perform the overall device reset:
1. From the System Configuration menu, select Reset.
The Reset menu appears (see Figure 4-50).
Note
