Installation and Operation Manual Chapter 4 Configuration
ASMi-52 Ver. 2.5 Configuring ASMi-52 for Management 4-3
Configuring the Host Parameters
ASMi-52 can be managed by a network management station, which is located on
the LAN connected to the 10/100BaseT port. In order to establish a proper
connection, it is necessary to configure the following: host IP address, subnet
mask, default gateway, its trap, read, and write communities.
To define the IP parameters:
1. From the Host IP menu (Main menu > Configuration > System Configuration
> Management > Host IP), type the following:
1 to define the host IP address
2 to define the subnet mask
3 to set the default gateway IP address
4 to enter the name of a community with read-only authorization
5 to enter the name of a community with write authorization
6 to enter the name of a community to which ASMi-52 will send traps.
2. Press <Enter>.
3. Press <Esc> to return to the Management menu (see Figure 4-1).
4. From the Management menu, select Save to save your changes.
ASMi-52
Host IP
1. Host IP address (172.17.161.73)
2. Host IP mask (255.255.255.0)
3. Host default gateway (172.17.161.1)
4. Read community (public)
5. Write community (public)
6. Trap community (public)
>
ESC-prev. menu; !-main menu; &-exit; @-scroll
Figure 4-4. Host IP Menu
Configuring the Network Managers
Define or modify the network management stations to which the SNMP agent of
ASMi-52 will send traps. Up to ten managers can be defined. Entering the IP
address and corresponding subnet mask to define each management station.
To configure the network managers:
1. Display the Manager List menu. (Main menu > Configuration > System
Configuration > Management > Manager List).
The Manager List menu appears (see Figure 4-5).
2. From the Manager List menu, type a number corresponding to the network
management station that you intend to define or modify, and enter its new IP
address.
