12. Alignment
Color Space Status
Projector
EBU
SMPTE
Custom
Custom2
ScenergiX Status
White level
Black level
ScenergiX pattern
Adjust lines
Reset
3D Glasses
Dark Time Adjustment
Actual Dark Time
L/R Output Reference Delay
3D Sync Loop Through
High End Systems Mirror Projector Controlled
Pan / Tilt
Store setting per layout
12.2 Orientation
What can be done?
The way of physical installation of the projector can be dened to the projector.
The following installation are possible:
front/table
front/ceiling
rear/table
rear/ceiling
auto front : automatic front, projector detects itself if it is ceiling or table mounted and projects always a readable image.
auto rear : automatic rear, projector detects itself if it is ceiling or table mounted and projects always a readable image.
How to set the correct orientation
1. Press Menu to activate the menus and select Alignme nt Orientation.
