Barco HDX Projector User Manual



B. Specifications
Optional Inputs 5-BNC RGBHV ( RGBS/RGsB, YUV CS/SOY, Composite video, S-Video); DVI - I (HDCP
including analog RGB YUV) + BarcoLink/SDI/HDSDI/dual HDSDI/3G; 3D active input
input(HDMI/DisplayPort) feat. SENSIO 3D
Input Resolutions from NTSC up to QXGA (2,048 x 1,536)
Pixel clock 200MHz
Software tools Projection Toolset + Android app
Control - XLR wired, IR, RS-232, DMX512 in/out, integrated web browser, Projection Toolset
- optional control over WiFi and GSM/mobile
Network connection 10/100 Mb/s Ethernet (on RJ45), WiFi
AC power 200-240 VAC/50-60 Hz
Power consumption 2,600 W / STBY <8 W
Noise level (typical at 25°C/77°F) 50 dB(A)
Operating temperature 0 ~ 40°C / 32 ~ 104°F
operation humidity no condens 0-80%
Dissipation BTU max. 8,871 BTU/h
Dimensions (WxLxH) 475 x 725 x 382 mm (18.7"” x 28.54" x 14.96")
Weight 50kg (110lbs)
Shipping Dimensions (LxWxH) 900 x 650 x 560 mm (35.43" x 25.59" x 22.04")
Standard accessories Power cord; wireless/XLR wired rugged remote control
Certications Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part
15 Class A and CE EN55022 Class A, RoHS
Warranty 2 years standard, extendable up to 5 years
B.3 Specications of the HDX W18
Overview
Projector type WUXGA 3-Chip DLP digital projector
Technology 0.96" DMD x 3
Resolution 1,920 x 1,200 (WUXGA)
Light output 18,000 Center lumens / 16,500 ANSI lumens
Contrast ratio 1,850:1 (standard) - 2,400:1 (high contrast mode)
Brightness uniformity 90%
Aspect Ratio 16:10
ScenergiX horizontal and vertical edge blending
Lens type
TLD +
Lens range
0.73:1 ; 1.2:1 ; 1.25-1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
Optical lens shift Vertical: -30% to +120% / Horizontal: -40% to +40% on zoom lenses (memorized)
Color correction P7
Lamps
2.5 kW Xenon
Lamp lifetime (typical) 1,000 hours
Transport with lamp Yes
Lamp house, quick replace Yes
Customer bulb replace Yes
Lamp warranty (eld replace/
factory replace)
90 days, 500 hours/pro rata 750 hours
Sealed DLP™ core Standard
Optical dowser Standard
R5905032 HDX SERIES 02/03/2015 309
